Extra Information

Standard Features

• Heavy-duty 4” square tubing frame
• Cleaning shoes feature exclusive eccentric drive with 1/2? throw for smooth seed flow and maximum seed separation.
• Reverse incline back fan unit generates up to 11,000 CFM @ 5? SP with 15 Hp drive.
• Drive setup can easily be adapted to your air and electrical requirements.
• Electronic variable speed vibratory inlet feed hopper with adjustable internal gate promotes uniform seed
• New-style heavy-duty screen cleaning ball trays allow screens to be c without removing ball trays.
• 2 calibrated air gate controls work with back adjustable doors to provide precise air separation settings.
• Replaceable metal screenways and rubber screen seals make future repairs easier.
• New-style shoe hangers and drive connectors enable smooth counterbalanced operation.
• Air lock discharge trash augers with bottom access door for easy cleanout.

Options

• 150-plus different standard screen sizes available. Additional screen sizes available upon request.
• Bottom blast fan integrated into existing frame to accommodate specialized air separation requirements.
• Grease line package for greasing machine from central location.
• Various 50 or 60 Hertz motor drive packages – single or 3 phase, TEFC or Ex-Proof.
• Side-mounted control panel for controlling electronic variable speeds from one location. Calibrated hopper gate control extended down to side of machine to ease of internal gate adjustment.
