Level fields, grade roads, remove snow, dig ditches, or
clean feedlots with complete control.
The ICON Pull Grader Model 1632RS by Landoll offers easy, accurate adjustments of your blade height,
tilt, and swing angle. Rear steering controls side drift. Fold-down box ends convert your
grader to a box scraper in minutes.
Features
-
Three-Way Hydraulic Operation to Raise/Lower, Tilt, and Blade Swing
-
Fold Down Box Ends on Blade
-
Rear Steering and Weight Box
-
Pintle Swivel Hitch
Extra Information
Landoll 1632RS efficiency and safety:
- Three-way hydraulic adjustments raise and lower the 16’ x 32” blade.
- Up to 45 degrees of right or left blade swing and 15 degrees tilt
- A 0.6 yard concrete weight at the rear provides 1,500 lbs. of down pressure on the cutting edge.
- Standard transport safety features include LED light kit, slow-moving vehicle sign, safety chain and yellow paint.
Features:
- Three-Way Hydraulic Operation to Raise/Lower, Tilt, and Blade Swing
- Integral Break-A-Way Valve on Blade for Unit Protection
- Fold Down Box Ends on Blade
- 19L x 16.1 Tires
- Rear Steering (Requires Additional Remote Circuit)
- Pintle Swivel Hitch
- Yellow Industrial Paint
- Safety Warning Lights
Specs
| Shipping Weight | 5,660 lbs. (with empty box) | |
| Working Width | 16' Width | |
| Transport Width | 11' Width | |
| Blade Size | 16' x 32" Blade | |
| Hitch | Pintle Swivel Hitch |
- Shipping Weight
- Working Width
- Transport Width
- Blade Size
- Hitch
-
ICON 1632RS
- 5,660 lbs. (with empty box)
- 16' Width
- 11' Width
- 16' x 32" Blade
- Pintle Swivel Hitch
